Car alarm with gps tracking function device Gt06

Larger Image : Car alarm with gps tracking function device Gt06

Product Details:

Place of Origin:Guangdong, China (Mainland)
Brand Name:Diwei
CE,FCC:CE,FCC

Payment & Shipping Terms:

Minimum Order Quantity:100 Piece/Pieces
Packaging Details:Package box demensions:130*90*60(mm) Net weight:142g Gross weight:250g
Delivery Time:1-2weeks
Payment Terms:T/T
Supply Ability:30,000 Piece/Pieces per Month
Detailed Product Description

Car alarm with gps tracking device Gt06

Built-in ON/OFF power, super-wide voltage input range(9-36V DC). Built-in vibration sensor, perform vehicle intelligent robbery protection. The only one global vehicle device built in double antenna (GSM+GPS). Compatible with external connection of device serial port communication.Be able to external connect a relay, remote control the vehicle gas and electricity.

 Car alarm with gps tracking device Gt06

Products Introduction:

  • GSM 850/900/1800/1900 Quad bad
  • GPS chipset with high sensitivity, High integration density
  • Built-in high sensitivity GPS antenna, extra strong receptivity
  • The only one global vehicle device built in double antenna (GSM+GPS)
  • Built-in ON/OFF power, wide voltage input range
  • Built-in vibration sensor, perform vehicle intelligent robbery protection
  • ACC detection, to upload status of vehicle operation
  • Be able to external connect cutoff relay to perform gas and electricity telecontrol
  • 3 special numbers for SOS alarm and burglar alarm
  • Be able to external connect SOS alarm button for emergency call
  • Be able to external connect microphone to perform voice monitor
  • Built-in backup battery to perform (illegal)
  • Compatible with external connection of device serial port communication

  Car alarm with gps tracking device Gt06

Features:

GSM

850/ 900/ 1800/ 1900 MHz

GPRS

Class12,TCP/ IP build in GSM Module

GPS

SIRF Star III

GPS Channels

20

Tracking sensitivity

-159dBm

Acquisition sensitivity

-144dBm

Locating time cost

Hot start: <2 sec(open sky)



Warm start: <15 sec



Cold start: <38 sec(open sky)

Antenna

Built-in GSM quad band antenna, GPS high gain antenna

Battery

500mAh

Monitoring range

5M

Voltage input range

5-36 VDC

LED indicator

Three LED indicator: GPS-blue, GSM-green, Power-red

Dimensions

98.0(L)× 52.0(W)× 15.0(H)mm

Weight

80g

Application environment

Operating temperature: -25°C to +70°C



Operating humidity: 5% to 95% non-condensing

 GSM Quad-band girdles the globe. High sensitive GPS chip (from USA). High integration density of waterproof design. Three special numbers for SOS alarm and burglar alarm. Built-in high sensitive GPS antenna, extra strong receptivity

Support ACC detection, to upload status of vehicle operation. Built-in backup battery to perform alarm when wire is cut illegally. Be able to external connect microphone to perform voice monitor. Be able to external connect SOS alarm button for emergency call.

Car alarm with gps tracking device Gt06

Car alarm with gps tracking device Gt06
